Depth Chart

Depth soundings of Hillsboro Inlet recorded 8-5-2019. Do not use for navigation.

Depth soundings taken from Hillsboro Inlet on August 5, 2019. Please note the following cautions when reading this information:

  1. This is a hazardous inlet, local knowledge is required.
  2. Chart is not to scale or intended for use for navigation.
  3. Pass at idle speed.
  4. Current at bridge can run at six knots. Give way to vessel moving with current.
  5. Ebb currents tend to push vessels onto the south reef.
  6. Flood currents tend to push vessels off the south reef.
  7. Moving sands reduce inlet depth.
  8. Wave troughs have less water depth than when flat calm.
